Details
- •Low-voltage industrial components
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Rated permanent current Iu160A
Conditioned rated short-circuit current Iq50kA
Suitable for fusesNH000, NH00
Number of poles4
Motor drive integratedNo
Cable entryOther
Degree of protection (IP), front sideIP30
Type of electrical connection of main circuitCable clamp
Max. rated operation voltage Ue AC500V
Rated operation power at AC-23, 400 V-kW
Version as emergency stop installationNo
Rated short-time withstand current lcw-kA
Version as safety switchYes
Version as main switchYes
Suitable for busbar mountingYes
Type of control elementOther
Suitable for floor mountingNo
With error protectionNo
Suitable for front mountingNo
Motor drive optionalNo
Position control elementFront side
Equipped with connectorsYes
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SEP600115R0002 | XLP00-4P-8BC
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Fuse switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Rated permanent current Iu
160A
Conditioned rated short-circuit current Iq
50kA
Suitable for fuses
NH000, NH00
Number of poles
4
Motor drive integrated
Cable entry
Other
Degree of protection (IP), front side
IP30
Type of electrical connection of main circuit
Cable clamp
Max. rated operation voltage Ue AC
500V
Rated operation power at AC-23, 400 V
-kW
Version as emergency stop installation
Rated short-time withstand current lcw
-kA
Version as safety switch
Version as main switch
Suitable for busbar mounting
Type of control element
Other
Suitable for floor mounting
With error protection
Suitable for front mounting
Motor drive optional
Position control element
Front side
Equipped with connectors
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
