Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •EATON
Technical specifications
Rated insulation voltage Ui440V
Over voltage category3
Rated voltage230V
Width in number of modular spacings1
Rated current2A
Number of protected poles1
Release characteristicB
Degree of protection (IP)IP20
Concurrently switching neutral conductorNo
Current limiting class3
Frequency50 - 60Hz
Pollution degree2
Built-in depth70.5mm
Ambient temperature during operating-25 - 75°C
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V10kA
Number of poles (total)1
Connectable conductor cross section solid-core1 - 25mm²
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V10kA
Additional equipment possibleYes
Connectable conductor cross section multi-wired1 - 25mm²
Suitable for flush-mounted installationNo
Voltage typeAC
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V0kA
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V0kA
Recommended products
From same serie
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
PL7-B2/1
