Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •EATON
Technical specifications
Frequency50 - 60Hz
Rated voltage400V
Built-in depth70.5mm
Release characteristicC
Voltage typeAC
Rated current63A
Current limiting class3
Rated insulation voltage Ui440V
Over voltage category3
Number of protected poles3
Pollution degree2
Width in number of modular spacings3
Connectable conductor cross section solid-core1 - 25mm²
Suitable for flush-mounted installationNo
Connectable conductor cross section multi-wired1 - 25mm²
Ambient temperature during operating-25 - 75°C
Degree of protection (IP)IP20
Concurrently switching neutral conductorNo
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V10kA
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V0kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V0kA
Number of poles (total)3
Additional equipment possibleYes
Recommended products
From same serie
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
PL7-C63/3
