Details
- •Low-voltage industrial components
- •Motor protection circuit-breaker
- •1 KOM
- •EATON
Technical specifications
With integrated under voltage releaseNo
With integrated auxiliary switchNo
Rated operation power at AC-3, 400 V0.12kW
Degree of protection (IP)IP20
Switch off techniqueMagnetic
Type of control elementTurn button
Power loss5.16W
Rated operation power at AC-3, 230 V0.09kW
Type of electrical connection of main circuitScrew connection
Rated operating voltage690 - 690V
Number of poles3
Device constructionBuilt-in device fixed built-in technique
Rated permanent current Iu0.63A
Depth35mm
Phase failure sensitiveNo
Overload release current setting0 - 0A
Rated short-circuit breaking capacity lcu at 400 V, AC150kA
Adjustment range undelayed short-circuit release9.8 - 9.8A
With thermal protectionNo
Width35mm
Height35mm
Related products
From same serie
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
PKM0-0,63
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Motor protection circuit-breaker
- 1 KOM
- EATON
DetailsTechnical specificationsRelated productsFrom same serie
Technical specifications
With integrated under voltage release
With integrated auxiliary switch
Rated operation power at AC-3, 400 V
0.12kW
Degree of protection (IP)
IP20
Switch off technique
Magnetic
Type of control element
Turn button
Power loss
5.16W
Rated operation power at AC-3, 230 V
0.09kW
Type of electrical connection of main circuit
Screw connection
Rated operating voltage
690 .. 690V
Number of poles
3
Device construction
Built-in device fixed built-in technique
Rated permanent current Iu
0.63A
Depth
35mm
Phase failure sensitive
Overload release current setting
0 .. 0A
Rated short-circuit breaking capacity lcu at 400 V, AC
150kA
Adjustment range undelayed short-circuit release
9.8 .. 9.8A
With thermal protection
Width
35mm
Height
35mm
