Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •EATON
Technical specifications
Release characteristicB
Number of poles (total)2
Built-in depth70.5mm
Rated current6A
Number of protected poles2
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V10kA
Rated insulation voltage Ui440V
Voltage typeAC
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V15kA
Current limiting class3
Frequency50 - 60Hz
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V15kA
Concurrently switching neutral conductorNo
Flush-mounted installationNo
Pollution degree2
Power loss3.6W
Over voltage category3
Width in number of modular spacings2
Connectable conductor cross section solid-core1 - 25mm²
Degree of protection (IP)IP20
Ambient temperature during operating-25 - 75°C
Rated voltage400V
Explosion-proofNo
Connectable conductor cross section multi-wired1 - 25mm²
Additional equipment possibleYes
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
FAZ-B6/2
