Details
- •Low-voltage industrial components
- •Power contactor, AC switching
- •1 KOM
- •EATON
Technical specifications
Width45mm
Depth97mm
Height85mm
Operating voltage at AC 60 Hz24 - 690V
Modular versionNo
Operating voltage at AC 50 Hz24 - 690V
Type of electrical connection of main circuitScrew connection
Voltage type for actuatingAC
Rated operation current Ie at AC-1, 400 V25A
Rated operation power at AC-4, 400 V11kW
Rated operation power NEMA11kW
Rated operation current Ie at AC-3, 400 V25A
Rated operation power at AC-3, 400 V11kW
Rated operation current Ie at AC-4, 400 V25A
Rated control supply voltage Us at AC 50HZ230 - 230V
Rated control supply voltage Us at DC0 - 0V
Number of normally open contacts as main contact3
Number of normally closed contacts as main contact0
Number of auxiliary contacts as normally closed contact0
Rated control supply voltage Us at AC 60HZ230 - 230V
Number of auxiliary contacts as normally open contact1
Related products
From same serie
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
DILM25-10(230V50/60HZ)
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Power contactor, AC switching
- 1 KOM
- EATON
DetailsTechnical specificationsRelated productsFrom same serie
Technical specifications
Width
45mm
Depth
97mm
Height
85mm
Operating voltage at AC 60 Hz
24 .. 690V
Modular version
Operating voltage at AC 50 Hz
24 .. 690V
Type of electrical connection of main circuit
Screw connection
Voltage type for actuating
AC
Rated operation current Ie at AC-1, 400 V
25A
Rated operation power at AC-4, 400 V
11kW
Rated operation power NEMA
11kW
Rated operation current Ie at AC-3, 400 V
25A
Rated operation power at AC-3, 400 V
11kW
Rated operation current Ie at AC-4, 400 V
25A
Rated control supply voltage Us at AC 50HZ
230 .. 230V
Rated control supply voltage Us at DC
0 .. 0V
Number of normally open contacts as main contact
3
Number of normally closed contacts as main contact
0
Number of auxiliary contacts as normally closed contact
0
Rated control supply voltage Us at AC 60HZ
230 .. 230V
Number of auxiliary contacts as normally open contact
1
From same serie
Related products
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
