PL6-C10/1
Code: 1015806
ManufacturerEaton
Catalog number286531
TypePL6-C10/1
CategoryMiniature circuit breaker (MCB)
EAN code4015082865313
Details
- •Automatski osigurac C10, 1 polni, 6 kA
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •Minimum order quantity: 1 pcs
- •EATON
Technical specifications
Voltage typeAC
Built-in depth70.5mm
Current limiting class3
Rated insulation voltage Ui440V
Frequency50 - 60Hz
Pollution degree2
Degree of protection (IP)IP20
Suitable for flush-mounted installationNo
Over voltage category3
Connectable conductor cross section solid-core1 - 25mm²
Ambient temperature during operating-25 - 75°C
Concurrently switching neutral conductorNo
Connectable conductor cross section multi-wired1 - 25mm²
Width in number of modular spacings1
Additional equipment possibleYes
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V6kA
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V0kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V0kA
Number of protected poles1
Rated voltage230V
Rated current10A
Release characteristicC
Number of poles (total)1
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V6kA
