Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •EATON
Technical specifications
Built-in depth70.5mm
Voltage typeAC
Rated current20A
Over voltage category3
Rated voltage230V
Degree of protection (IP)IP20
Pollution degree2
Number of protected poles1
Current limiting class3
Width in number of modular spacings1
Concurrently switching neutral conductorNo
Rated insulation voltage Ui440V
Frequency50 - 60Hz
Release characteristicC
Connectable conductor cross section solid-core1 - 25mm²
Additional equipment possibleYes
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V6kA
Ambient temperature during operating-25 - 75°C
Number of poles (total)1
Connectable conductor cross section multi-wired1 - 25mm²
Suitable for flush-mounted installationNo
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V6kA
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V0kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V0kA
Related products
Recommended products
From same serie
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
PL6-C20/1
