Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •EATON
Technical specifications
Voltage typeAC
Built-in depth70.5mm
Current limiting class3
Frequency50 - 60Hz
Rated voltage400V
Rated current16A
Rated insulation voltage Ui440V
Release characteristicC
Over voltage category3
Pollution degree2
Concurrently switching neutral conductorNo
Number of protected poles3
Degree of protection (IP)IP20
Additional equipment possibleYes
Ambient temperature during operating-25 - 75°C
Width in number of modular spacings3
Connectable conductor cross section solid-core1 - 25mm²
Suitable for flush-mounted installationNo
Connectable conductor cross section multi-wired1 - 25mm²
Number of poles (total)3
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V0kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V6kA
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V0kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V6kA
