Details
- •Low-voltage industrial components
- •Power circuit-breaker for trafo/generator/installation protection
- •1 KOM
- •EATON
Technical specifications
Integrated earth fault protectionNo
Adjustment range undelayed short-circuit release800 - 4400A
Position of connection for main current circuitFront side
Overload release current setting200 - 400A
Number of poles3
With switched-off indicatorNo
Suitable for DIN rail (top hat rail) mountingNo
Motor drive integratedNo
Rated voltage690 - 690V
Type of control elementRocker lever
Type of electrical connection of main circuitScrew connection
Number of auxiliary contacts as normally closed contact0
Adjustment range short-term delayed short-circuit release0 - 0A
Degree of protection (IP)IP20
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz50kA
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as change-over contact0
Rated permanent current Iu400A
With integrated under voltage releaseNo
Motor drive optionalYes
Complete device with protection unitYes
DIN rail (top hat rail) mounting optionalNo
Device constructionBuilt-in device fixed built-in technique
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
NZMN3-AE400
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Power circuit-breaker for trafo/generator/installation protection
- 1 KOM
- EATON
DetailsTechnical specificationsRelated products
Technical specifications
Integrated earth fault protection
Adjustment range undelayed short-circuit release
800 .. 4400A
Position of connection for main current circuit
Front side
Overload release current setting
200 .. 400A
Number of poles
3
With switched-off indicator
Suitable for DIN rail (top hat rail) mounting
Motor drive integrated
Rated voltage
690 .. 690V
Type of control element
Rocker lever
Type of electrical connection of main circuit
Screw connection
Number of auxiliary contacts as normally closed contact
0
Adjustment range short-term delayed short-circuit release
0 .. 0A
Degree of protection (IP)
IP20
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz
50kA
Number of auxiliary contacts as normally open contact
0
Number of auxiliary contacts as change-over contact
0
Rated permanent current Iu
400A
With integrated under voltage release
Motor drive optional
Complete device with protection unit
DIN rail (top hat rail) mounting optional
Device construction
Built-in device fixed built-in technique
