Details
- •Domestic switching devices
- •Socket outlet
- •1 KOM
- •ABB
Technical specifications
ColourGreen
Nominal current10A
Connection typeScrewed terminal
LockableNo
With hinged lidNo
Mounting methodFlush mounted (plaster)
ModelItalian type P11
Number of units1
Surface protectionOther
Nominal voltage250V
Halogen freeYes
With signal lampNo
With on/off switchNo
With enhanced contact protectionYes
Label space/information surfaceNo
Number of phases0
Frequency50 - 60Hz
Protective contactYes
Fault current protectionYes
Material qualityThermoplastic
Rotated central insertNo
Rated fault current10mA
Special power supplySafety power supply (green)
Over voltage protectionYes
MaterialPlastic
Eject-mechanismNo
Insulated mountingNo
Type of fasteningSnap mounting (engagement)
Impact strengthIK04
With miniature fuseNo
Surface finishingMatt
For heavy conditions (according to VDE)No
RAL-number (similar)-
With loop through functionYes
TransparentNo
Imprint/indicationWithout imprint
Suitable for degree of protection (IP)IP20
Number of active pins (round)2
With orientation lightingNo
Protective earth pin roundYes
Width of device22mm
Number of modules (module system)1
Number of socket outlets switchable1
With function lightingNo
Number of active pins (flat)3
Anti-bacterial treatmentNo
Height of device45mm
Min. depth of built-in installation box36mm
With built-in USB power supplyNo
Depth of device40mm
From same serie
