Details
- •Circuit breakers and fuses
- •Residual current circuit breaker (RCCB)
- •1 KOM
- •EATON
Technical specifications
Mounting methodDIN rail
Rated fault current30mA
Rated voltage230V
Built-in depth69.5mm
Rated current63A
Selective protectionNo
Number of poles2
Short-circuit breaking capacity (Icw)6kA
Surge current capacity0.25kA
Pollution degree2
Leakage current typeAC
Rated insulation voltage Ui440V
Short-time delayed trippingNo
Connectable conductor cross section multi-wired1.5 - 16mm²
With interlocking deviceYes
Connectable conductor cross section solid-core1.5 - 35mm²
Degree of protection (IP)IP20
Width in number of modular spacings2
Rated impulse withstand voltage Uimp4kV
Additional equipment possibleYes
Ambient temperature during operating-25 - 40°C
Frequency50 Hz
From same serie
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
PF6-63/2/003
