Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •EATON
Technical specifications
Built-in depth69.5mm
Rated current6A
Voltage typeAC
Rated insulation voltage Ui440V
Release characteristicB
Width in number of modular spacings2
Rated voltage230V
Frequency50 Hz
Rated fault current0.03A
Degree of protection (IP)IP20
Leakage current typeAC
Pollution degree2
Surge current capacity0.25kA
Suitable for flush-mounted installationNo
Rated short-circuit breaking capacity according to IEC 60947-20kA
Number of protected poles1
Over voltage category3
Connectable conductor cross section solid-core1 - 25mm²
Current limiting class3
Concurrently switching neutral conductorYes
Connectable conductor cross section multi-wired1 - 25mm²
Anti-nuisance tripping versionNo
Rated short-circuit breaking capacity Icn according to EN 61009-110kA
Number of poles (total)2
Rated impulse withstand voltage Uimp4kV
Ambient temperature during operating-25 - 40°C
With interlocking deviceNo
Rated short-circuit breaking capacity according to EN 6100910kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
PFL7-6/1N/B/003
