Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •EATON
Technical specifications
Rated insulation voltage Ui440V
Built-in depth69.5mm
Surge current capacity0.25kA
Leakage current typeAC
Rated voltage230V
Release characteristicB
Rated fault current0.03A
Voltage typeAC
Current limiting class3
Rated current13A
Number of protected poles1
Frequency50 Hz
Over voltage category3
Ambient temperature during operating-25 - 40°C
Number of poles (total)2
Suitable for flush-mounted installationNo
Concurrently switching neutral conductorYes
Pollution degree2
Connectable conductor cross section multi-wired1 - 25mm²
Connectable conductor cross section solid-core1 - 25mm²
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity according to EN 6100910kA
Width in number of modular spacings2
Anti-nuisance tripping versionNo
Degree of protection (IP)IP20
Rated short-circuit breaking capacity according to IEC 60947-20kA
With interlocking deviceNo
Rated short-circuit breaking capacity Icn according to EN 61009-110kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
PFL7-13/1N/B/003
