PLHT-C125
Code: 1024010
Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •EATON
Technical specifications
Degree of protection (IP)IP20
Voltage typeAC
Suitable for flush-mounted installationNo
Rated current125A
Built-in depth75mm
Width in number of modular spacings1.5
Rated voltage400V
Release characteristicC
Ambient temperature during operating-25 - 55°C
Connectable conductor cross section multi-wired2.5 - 50mm²
Number of protected poles1
Connectable conductor cross section solid-core2.5 - 50mm²
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V15kA
Rated insulation voltage Ui440V
Over voltage category3
Rated impulse withstand voltage Uimp4kV
Number of poles (total)1
Current limiting class3
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V15kA
Additional equipment possibleYes
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V0kA
Pollution degree2
Frequency50 - 60Hz
Concurrently switching neutral conductorNo
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V0kA
From same serie
