Z-MS-16/2
Code: 1024138
ManufacturerEaton
Catalog number248399
TypeZ-MS-16/2
CategoryMotor protection circuit-breaker
EAN code4015082483999
Details
- •Low-voltage industrial components
- •Motor protection circuit-breaker
- •1 KOM
- •EATON
Technical specifications
Degree of protection (IP)IP20
Type of electrical connection of main circuitScrew connection
Switch off techniqueMagnetic
Height75mm
With integrated auxiliary switchNo
Depth80mm
Type of control elementRocker lever
With thermal protectionYes
Rated operating voltage400 - 400V
With integrated under voltage releaseNo
Width36mm
Device constructionComplete device in housing
Phase failure sensitiveNo
Rated operation power at AC-3, 230 V0kW
Adjustment range undelayed short-circuit release160 - 208A
Rated operation power at AC-3, 400 V7.5kW
Rated permanent current Iu16A
Number of poles2
Overload release current setting10 - 16A
Rated short-circuit breaking capacity lcu at 400 V, AC10kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
Z-MS-16/2
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Motor protection circuit-breaker
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Degree of protection (IP)
IP20
Type of electrical connection of main circuit
Screw connection
Switch off technique
Magnetic
Height
75mm
With integrated auxiliary switch
Depth
80mm
Type of control element
Rocker lever
With thermal protection
Rated operating voltage
400 .. 400V
With integrated under voltage release
Width
36mm
Device construction
Complete device in housing
Phase failure sensitive
Rated operation power at AC-3, 230 V
0kW
Adjustment range undelayed short-circuit release
160 .. 208A
Rated operation power at AC-3, 400 V
7.5kW
Rated permanent current Iu
16A
Number of poles
2
Overload release current setting
10 .. 16A
Rated short-circuit breaking capacity lcu at 400 V, AC
10kA
