PL6-C13/1
Code: 1025199
Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •EATON
Technical specifications
Degree of protection (IP)IP20
Voltage typeAC
Suitable for flush-mounted installationNo
Rated voltage230V
Built-in depth70.5mm
Width in number of modular spacings1
Rated current13A
Release characteristicC
Ambient temperature during operating-25 - 75°C
Connectable conductor cross section multi-wired1 - 25mm²
Number of protected poles1
Connectable conductor cross section solid-core1 - 25mm²
Over voltage category3
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V0kA
Number of poles (total)1
Rated insulation voltage Ui440V
Current limiting class3
Additional equipment possibleYes
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V0kA
Pollution degree2
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V6kA
Concurrently switching neutral conductorNo
Frequency50 - 60Hz
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V6kA
