Details
- •Sensors
- •End switch
- •1 KOM
- •EATON
Technical specifications
Switching functionQuick-break switch
Type of interface for safety communicationNone
Coating housingOther
Suitable for safety functionsYes
With status indicationNo
Rated operation current Ie at DC-13, 230 V0.3A
Explosion safety category for gasNone
Explosion safety category for dustNone
Rated operation current Ie at AC-15, 230 V6A
Type of electric connectionCable entry metrical
Material housingPlastic
Construction type housingCuboid
Rated operation current Ie at AC-15, 125 V6A
Type of control elementRotary lever
Type of interfaceNone
Rated operation current Ie at DC-13, 24 V3A
Output electronicNo
Forced openingYes
Rated operation current Ie at AC-15, 24 V6A
Rated operation current Ie at DC-13, 125 V0.8A
Degree of protection (IP)IP66/IP67
Number of safety auxiliary contacts1
Length of sensor33.5mm
Height of sensor61mm
Width sensor31mm
Diameter sensor0mm
Switching function latchingNo
Number of contacts as normally open contact1
Ambient temperature during operating-25 - 70°C
Number of contacts as normally closed contact1
Number of contacts as change-over contact0
Degree of protection (NEMA)Other
Alignment of the control elementRoller cam crossed
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
LS-11S/RL
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- End switch
- 1 KOM
- EATON
DetailsTechnical specificationsRelated products
Technical specifications
Switching function
Quick-break switch
Type of interface for safety communication
None
Coating housing
Other
Suitable for safety functions
With status indication
Rated operation current Ie at DC-13, 230 V
0.3A
Explosion safety category for gas
None
Explosion safety category for dust
None
Rated operation current Ie at AC-15, 230 V
6A
Type of electric connection
Cable entry metrical
Material housing
Plastic
Construction type housing
Cuboid
Rated operation current Ie at AC-15, 125 V
6A
Type of control element
Rotary lever
Type of interface
None
Rated operation current Ie at DC-13, 24 V
3A
Output electronic
Forced opening
Rated operation current Ie at AC-15, 24 V
6A
Rated operation current Ie at DC-13, 125 V
0.8A
Degree of protection (IP)
IP66/IP67
Number of safety auxiliary contacts
1
Length of sensor
33.5mm
Height of sensor
61mm
Width sensor
31mm
Diameter sensor
0mm
Switching function latching
Number of contacts as normally open contact
1
Ambient temperature during operating
-25 .. 70°C
Number of contacts as normally closed contact
1
Number of contacts as change-over contact
0
Degree of protection (NEMA)
Other
Alignment of the control element
Roller cam crossed
