Details
- •Sensors
- •End switch
- •1 KOM
- •EATON
Technical specifications
Switching functionSlow-action switch
Type of electric connectionCable entry metrical
Number of safety auxiliary contacts0
Degree of protection (IP)IP66/IP67
Explosion safety category for dustNone
Forced openingYes
Construction type housingCuboid
Rated operation current Ie at DC-13, 230 V0.3A
Material housingMetal
With status indicationNo
Rated operation current Ie at AC-15, 230 V6A
Explosion safety category for gasNone
Coating housingOther
Type of interface for safety communicationNone
Suitable for safety functionsYes
Type of control elementPlunger
Rated operation current Ie at AC-15, 125 V6A
Type of interfaceNone
Output electronicNo
Rated operation current Ie at DC-13, 125 V0.8A
Diameter sensor0mm
Number of contacts as normally closed contact2
Height of sensor61mm
Rated operation current Ie at AC-15, 24 V6A
Number of contacts as change-over contact0
Ambient temperature during operating-25 - 70°C
Rated operation current Ie at DC-13, 24 V3A
Length of sensor33.5mm
Width sensor31mm
Switching function latchingNo
Number of contacts as normally open contact0
Alignment of the control elementRoller cam straight
Degree of protection (NEMA)Other
Related products
From same serie
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
LSM-02
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- End switch
- 1 KOM
- EATON
DetailsTechnical specificationsRelated productsFrom same serie
Technical specifications
Switching function
Slow-action switch
Type of electric connection
Cable entry metrical
Number of safety auxiliary contacts
0
Degree of protection (IP)
IP66/IP67
Explosion safety category for dust
None
Forced opening
Construction type housing
Cuboid
Rated operation current Ie at DC-13, 230 V
0.3A
Material housing
Metal
With status indication
Rated operation current Ie at AC-15, 230 V
6A
Explosion safety category for gas
None
Coating housing
Other
Type of interface for safety communication
None
Suitable for safety functions
Type of control element
Plunger
Rated operation current Ie at AC-15, 125 V
6A
Type of interface
None
Output electronic
Rated operation current Ie at DC-13, 125 V
0.8A
Diameter sensor
0mm
Number of contacts as normally closed contact
2
Height of sensor
61mm
Rated operation current Ie at AC-15, 24 V
6A
Number of contacts as change-over contact
0
Ambient temperature during operating
-25 .. 70°C
Rated operation current Ie at DC-13, 24 V
3A
Length of sensor
33.5mm
Width sensor
31mm
Switching function latching
Number of contacts as normally open contact
0
Alignment of the control element
Roller cam straight
Degree of protection (NEMA)
Other
From same serie
