Details
- •Sensors for automation technology
- •End switch
- •1 KOM
- •EATON
Technical specifications
Rated operation current Ie at AC-15, 230 V6A
Switching functionQuick-break switch
Rated operation current Ie at DC-13, 230 V0.3A
Coating housingOther
Material housingMetal
Suitable for safety functionsYes
Explosion safety category for dustNone
Type of electric connectionCable entry metrical
Type of interfaceNone
Construction type housingCuboid
Rated operation current Ie at AC-15, 24 V6A
Explosion safety category for gasNone
Type of interface for safety communicationNone
Degree of protection (IP)IP66/IP67
Rated operation current Ie at AC-15, 125 V6A
Number of contacts as normally open contact1
Diameter sensor0mm
Type of control elementRotary lever
With status indicationNo
Output electronicNo
Length of sensor33.5mm
Number of contacts as normally closed contact1
Forced openingYes
Switching function latchingNo
Ambient temperature during operating-25 - 70°C
Width sensor31mm
Height of sensor61mm
Number of contacts as change-over contact0
Rated operation current Ie at DC-13, 24 V3A
Number of safety auxiliary contacts0
Rated operation current Ie at DC-13, 125 V0.8A
Degree of protection (NEMA)Other
Alignment of the control elementRoller cam crossed
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
LSM-11S/RL
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors for automation technology
- End switch
- 1 KOM
- EATON
DetailsTechnical specificationsRelated products
Technical specifications
Rated operation current Ie at AC-15, 230 V
6A
Switching function
Quick-break switch
Rated operation current Ie at DC-13, 230 V
0.3A
Coating housing
Other
Material housing
Metal
Suitable for safety functions
Explosion safety category for dust
None
Type of electric connection
Cable entry metrical
Type of interface
None
Construction type housing
Cuboid
Rated operation current Ie at AC-15, 24 V
6A
Explosion safety category for gas
None
Type of interface for safety communication
None
Degree of protection (IP)
IP66/IP67
Rated operation current Ie at AC-15, 125 V
6A
Number of contacts as normally open contact
1
Diameter sensor
0mm
Type of control element
Rotary lever
With status indication
Output electronic
Length of sensor
33.5mm
Number of contacts as normally closed contact
1
Forced opening
Switching function latching
Ambient temperature during operating
-25 .. 70°C
Width sensor
31mm
Height of sensor
61mm
Number of contacts as change-over contact
0
Rated operation current Ie at DC-13, 24 V
3A
Number of safety auxiliary contacts
0
Rated operation current Ie at DC-13, 125 V
0.8A
Degree of protection (NEMA)
Other
Alignment of the control element
Roller cam crossed
