Details
- •Sensors
- •End switch
- •1 KOM
- •EATON
Technical specifications
Material housingMetal
Switching functionSlow-action switch
Type of interface for safety communicationNone
Rated operation current Ie at DC-13, 230 V0.3A
Number of safety auxiliary contacts0
Rated operation current Ie at AC-15, 230 V6A
Output electronicNo
Type of interfaceNone
Suitable for safety functionsNo
Rated operation current Ie at AC-15, 24 V6A
Explosion safety category for gasNone
Type of control elementPlunger
Forced openingNo
Rated operation current Ie at AC-15, 125 V6A
With status indicationNo
Coating housingOther
Degree of protection (IP)IP66/IP67
Construction type housingCuboid
Type of electric connectionCable entry metrical
Explosion safety category for dustNone
Ambient temperature during operating-25 - 70°C
Rated operation current Ie at DC-13, 125 V0.8A
Length of sensor33.5mm
Height of sensor61mm
Degree of protection (NEMA)Other
Diameter sensor0mm
Width sensor31mm
Number of contacts as normally closed contact0
Rated operation current Ie at DC-13, 24 V3A
Number of contacts as change-over contact0
Alignment of the control elementRoller cam straight
Number of contacts as normally open contact2
Switching function latchingNo
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
LSM-20
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- End switch
- 1 KOM
- EATON
DetailsTechnical specificationsRelated products
Technical specifications
Material housing
Metal
Switching function
Slow-action switch
Type of interface for safety communication
None
Rated operation current Ie at DC-13, 230 V
0.3A
Number of safety auxiliary contacts
0
Rated operation current Ie at AC-15, 230 V
6A
Output electronic
Type of interface
None
Suitable for safety functions
Rated operation current Ie at AC-15, 24 V
6A
Explosion safety category for gas
None
Type of control element
Plunger
Forced opening
Rated operation current Ie at AC-15, 125 V
6A
With status indication
Coating housing
Other
Degree of protection (IP)
IP66/IP67
Construction type housing
Cuboid
Type of electric connection
Cable entry metrical
Explosion safety category for dust
None
Ambient temperature during operating
-25 .. 70°C
Rated operation current Ie at DC-13, 125 V
0.8A
Length of sensor
33.5mm
Height of sensor
61mm
Degree of protection (NEMA)
Other
Diameter sensor
0mm
Width sensor
31mm
Number of contacts as normally closed contact
0
Rated operation current Ie at DC-13, 24 V
3A
Number of contacts as change-over contact
0
Alignment of the control element
Roller cam straight
Number of contacts as normally open contact
2
Switching function latching
