Technical specifications
Switching functionQuick-break switch
Degree of protection (IP)IP66/IP67
Explosion safety category for dustNone
Type of interface for safety communicationNone
Coating housingOther
Forced openingYes
Rated operation current Ie at AC-15, 230 V6A
Suitable for safety functionsYes
Rated operation current Ie at DC-13, 230 V0.3A
Type of electric connectionCable entry metrical
Explosion safety category for gasNone
With status indicationNo
Type of control elementPlunger
Rated operation current Ie at DC-13, 125 V0.8A
Output electronicNo
Width sensor31mm
Height of sensor61mm
Diameter sensor0mm
Construction type housingCuboid
Number of safety auxiliary contacts1
Rated operation current Ie at DC-13, 24 V3A
Rated operation current Ie at AC-15, 125 V6A
Type of interfaceNone
Rated operation current Ie at AC-15, 24 V6A
Material housingPlastic
Degree of protection (NEMA)Other
Number of contacts as normally closed contact1
Length of sensor33.5mm
Number of contacts as change-over contact0
Switching function latchingNo
Number of contacts as normally open contact1
Ambient temperature during operating-25 - 70°C
Alignment of the control elementRoller cam straight
