Details
- •Sensors
- •End switch
- •1 KOM
- •EATON
Technical specifications
Rated operation current Ie at AC-15, 230 V6A
Switching functionSlow-action switch
Suitable for safety functionsNo
Type of interface for safety communicationNone
Coating housingOther
Rated operation current Ie at DC-13, 230 V0.3A
Construction type housingCuboid
Type of electric connectionCable entry metrical
Explosion safety category for gasNone
With status indicationNo
Material housingMetal
Type of interfaceNone
Explosion safety category for dustNone
Type of control elementPlunger
Forced openingNo
Number of safety auxiliary contacts0
Degree of protection (IP)IP66/IP67
Diameter sensor0mm
Rated operation current Ie at AC-15, 125 V6A
Rated operation current Ie at AC-15, 24 V6A
Height of sensor61mm
Output electronicNo
Rated operation current Ie at DC-13, 125 V0.8A
Length of sensor33.5mm
Rated operation current Ie at DC-13, 24 V3A
Width sensor31mm
Switching function latchingNo
Number of contacts as normally closed contact0
Ambient temperature during operating-25 - 70°C
Number of contacts as change-over contact0
Number of contacts as normally open contact2
Degree of protection (NEMA)Other
Alignment of the control elementRoller cam straight
