T3-4-8344/V/SVB-SW
Code: 1033694
Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •EATON
Technical specifications
Max. rated operation voltage Ue AC690V
Rated permanent current at AC-23, 400 V32A
Version as maintenance-/service switchYes
Version as main switchYes
Number of switches1
Version as reversing switchNo
Version as emergency stop installationNo
Rated permanent current Iu32A
Version as safety switchNo
Rated operation power at AC-3, 400 V11kW
Rated permanent current at AC-21, 400 V32A
Switching power at 400 V15kW
Rated short-time withstand current lcw0.65kA
Rated operation power at AC-23, 400 V15kW
Number of auxiliary contacts as normally closed contact0
Conditioned rated short-circuit current Iq1kA
Number of auxiliary contacts as normally open contact0
Number of poles8
Rated operating voltage690 - 690V
Motor drive optionalNo
Device constructionBuilt-in device fixed built-in technique
Suitable for front mounting centreNo
Voltage release optionalNo
Suitable for intermediate mountingYes
Suitable for distribution board installationNo
Colour control elementBlack
Type of control elementDoor coupling rotary drive
Type of electrical connection of main circuitScrew connection
With pre-assembled cablingNo
Degree of protection (NEMA)12
Width65mm
InterlockableYes
Height74mm
Number of auxiliary contacts as change-over contact0
Depth156mm
Suitable for floor mountingYes
Suitable for front mounting 4-holeNo
Motor drive integratedNo
Degree of protection (IP), front sideIP65
Related products
