Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •EATON
Technical specifications
Colour control elementRed
Version as safety switchNo
Conditioned rated short-circuit current Iq4kA
Motor drive integratedNo
Version as maintenance-/service switchYes
Type of electrical connection of main circuitScrew connection
Rated operation power at AC-23, 400 V55kW
InterlockableYes
Rated permanent current Iu100A
Number of auxiliary contacts as normally open contact2
Degree of protection (IP), front sideIP65
Rated short-time withstand current lcw2kA
Type of control elementDoor coupling rotary drive
Number of switches1
Version as emergency stop installationYes
Number of poles3
Number of auxiliary contacts as change-over contact0
Rated operating voltage690 - 690V
Rated operation power at AC-3, 400 V37kW
Number of auxiliary contacts as normally closed contact2
Version as main switchYes
Suitable for front mounting centreNo
Suitable for distribution board installationNo
Suitable for front mounting 4-holeYes
Suitable for floor mountingNo
Max. rated operation voltage Ue AC690V
Motor drive optionalNo
Rated permanent current at AC-21, 400 V100A
Rated permanent current at AC-23, 400 V100A
Voltage release optionalNo
Switching power at 400 V55kW
Suitable for intermediate mountingNo
Degree of protection (NEMA)12
Version as reversing switchNo
Device constructionBuilt-in device fixed built-in technique
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
P3-100/EA/SVB/2HI11
