Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •EATON
Technical specifications
Height74mm
Width65mm
Depth104mm
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as normally closed contact0
Rated operation power at AC-3, 400 V11kW
Degree of protection (IP), front sideIP65
Rated operating voltage690 - 690V
InterlockableYes
Number of switches1
Conditioned rated short-circuit current Iq1kA
Number of poles2
Number of auxiliary contacts as change-over contact0
Version as emergency stop installationYes
Type of electrical connection of main circuitScrew connection
Motor drive integratedNo
Version as safety switchNo
Version as main switchYes
Version as maintenance-/service switchYes
Rated operation power at AC-23, 400 V15kW
Suitable for floor mountingNo
Rated short-time withstand current lcw0.65kA
Suitable for intermediate mountingNo
Motor drive optionalNo
Colour control elementRed
Max. rated operation voltage Ue AC690V
Suitable for front mounting 4-holeNo
Rated permanent current Iu32A
Suitable for distribution board installationNo
Suitable for front mounting centreYes
Type of control elementDoor coupling rotary drive
Voltage release optionalNo
Switching power at 400 V15kW
Device constructionBuilt-in device fixed built-in technique
Rated permanent current at AC-21, 400 V32A
With pre-assembled cablingNo
Rated permanent current at AC-23, 400 V32A
Version as reversing switchNo
Degree of protection (NEMA)12
