Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •EATON
Technical specifications
Width83mm
Rated permanent current Iu25A
Rated operation power at AC-3, 400 V7.5kW
Version as emergency stop installationNo
InterlockableYes
Number of poles4
Height65mm
Number of auxiliary contacts as change-over contact0
Degree of protection (IP), front sideIP65
Motor drive integratedNo
Number of auxiliary contacts as normally closed contact1
Type of electrical connection of main circuitScrew connection
Depth119mm
Number of switches1
Number of auxiliary contacts as normally open contact1
Conditioned rated short-circuit current Iq50kA
Version as maintenance-/service switchYes
Version as main switchYes
Version as safety switchNo
Type of control elementDoor coupling rotary drive
Rated operating voltage690 - 690V
Suitable for front mounting 4-holeYes
Colour control elementBlack
Rated operation power at AC-23, 400 V13kW
Rated short-time withstand current lcw0.64kA
Version as reversing switchNo
Suitable for front mounting centreNo
Suitable for floor mountingNo
Rated permanent current at AC-21, 400 V25A
Device constructionBuilt-in device fixed built-in technique
Degree of protection (NEMA)12
Suitable for distribution board installationNo
Max. rated operation voltage Ue AC690V
Rated permanent current at AC-23, 400 V25A
With pre-assembled cablingNo
Suitable for intermediate mountingNo
Motor drive optionalNo
Switching power at 400 V13kW
Voltage release optionalNo
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
P1-25/EA/SVB-SW/N/HI11
