Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •EATON
Technical specifications
Number of poles6
Height88mm
Depth156mm
Rated operation power at AC-3, 400 V22kW
Rated permanent current Iu63A
Width88mm
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Version as emergency stop installationNo
Type of control elementDoor coupling rotary drive
Degree of protection (IP), front sideIP65
Conditioned rated short-circuit current Iq2kA
Motor drive integratedNo
Number of auxiliary contacts as change-over contact0
Type of electrical connection of main circuitScrew connection
Version as main switchYes
Rated operation power at AC-23, 400 V30kW
Number of switches1
Version as maintenance-/service switchYes
InterlockableYes
Rated operating voltage690 - 690V
Version as safety switchNo
Suitable for floor mountingNo
Switching power at 400 V30kW
Suitable for intermediate mountingNo
Max. rated operation voltage Ue AC690V
Motor drive optionalNo
Colour control elementBlack
Device constructionBuilt-in device fixed built-in technique
Rated short-time withstand current lcw1.3kA
Rated permanent current at AC-21, 400 V63A
Suitable for front mounting centreYes
Version as reversing switchNo
Suitable for front mounting 4-holeNo
Degree of protection (NEMA)12
Suitable for distribution board installationNo
Voltage release optionalNo
With pre-assembled cablingNo
Rated permanent current at AC-23, 400 V63A
