Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •EATON
Technical specifications
Rated permanent current Iu20A
Number of poles2
Number of auxiliary contacts as normally closed contact0
Conditioned rated short-circuit current Iq6kA
Number of auxiliary contacts as normally open contact0
Rated operation power at AC-3, 400 V5.5kW
Depth118mm
Height74mm
Width65mm
Rated operating voltage690 - 690V
Motor drive integratedNo
InterlockableYes
Version as emergency stop installationYes
Number of auxiliary contacts as change-over contact0
Type of electrical connection of main circuitScrew connection
Type of control elementDoor coupling rotary drive
Degree of protection (IP), front sideIP65
Number of switches1
Version as main switchYes
Suitable for floor mountingYes
Colour control elementRed
Rated operation power at AC-23, 400 V5.5kW
Version as maintenance-/service switchYes
Suitable for front mounting centreNo
Rated short-time withstand current lcw0.32kA
Suitable for distribution board installationNo
Suitable for intermediate mountingYes
Voltage release optionalNo
Switching power at 400 V5.5kW
Version as reversing switchNo
Suitable for front mounting 4-holeNo
Rated permanent current at AC-21, 400 V20A
Version as safety switchNo
Device constructionBuilt-in device fixed built-in technique
Motor drive optionalNo
Max. rated operation voltage Ue AC690V
Rated permanent current at AC-23, 400 V13.3A
Degree of protection (NEMA)12
With pre-assembled cablingNo
