T0-1-102/E/SVB
Code: 1042971
Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •EATON
Technical specifications
Version as main switchYes
Version as emergency stop installationYes
Rated permanent current at AC-23, 400 V13.3A
Rated operation power at AC-3, 400 V5.5kW
Max. rated operation voltage Ue AC690V
Version as maintenance-/service switchYes
Number of switches1
Switching power at 400 V5.5kW
Rated operating voltage690 - 690V
Version as safety switchNo
Version as reversing switchNo
Rated permanent current at AC-21, 400 V20A
Number of auxiliary contacts as normally closed contact0
Rated operation power at AC-23, 400 V5.5kW
Conditioned rated short-circuit current Iq6kA
Motor drive optionalNo
Rated permanent current Iu20A
Number of poles2
Rated short-time withstand current lcw0.32kA
Number of auxiliary contacts as change-over contact0
Suitable for front mounting 4-holeYes
Motor drive integratedNo
InterlockableYes
Suitable for distribution board installationNo
Voltage release optionalNo
Colour control elementRed
Suitable for floor mountingNo
Device constructionBuilt-in device fixed built-in technique
Type of control elementDoor coupling rotary drive
Type of electrical connection of main circuitScrew connection
Suitable for front mounting centreNo
Suitable for intermediate mountingNo
Number of auxiliary contacts as normally open contact0
With pre-assembled cablingNo
Degree of protection (IP), front sideIP65
Height74mm
Degree of protection (NEMA)12
Depth80mm
Width65mm
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
