Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •EATON
Technical specifications
Number of auxiliary contacts as normally open contact0
Number of poles1
Rated operating voltage690 - 690V
Conditioned rated short-circuit current Iq6kA
Rated operation power at AC-3, 400 V5.5kW
Rated permanent current Iu20A
Number of auxiliary contacts as normally closed contact0
Motor drive integratedNo
InterlockableNo
Number of auxiliary contacts as change-over contact0
Number of switches1
Degree of protection (IP), front sideIP65
Version as safety switchNo
Type of control elementToggle
Version as main switchNo
Type of electrical connection of main circuitScrew connection
Voltage release optionalNo
Colour control elementRed
Rated short-time withstand current lcw0.32kA
Suitable for distribution board installationNo
Version as emergency stop installationYes
Max. rated operation voltage Ue AC690V
Suitable for front mounting centreNo
Rated permanent current at AC-21, 400 V20A
Version as maintenance-/service switchNo
Suitable for floor mountingYes
Switching power at 400 V5.5kW
Rated operation power at AC-23, 400 V5.5kW
Suitable for front mounting 4-holeNo
Device constructionComplete device in housing
Suitable for intermediate mountingNo
Motor drive optionalNo
Degree of protection (NEMA)Other
Version as reversing switchNo
Rated permanent current at AC-23, 400 V13.3A
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
T0-1-8200/I1-RT
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Switch disconnector
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Number of auxiliary contacts as normally open contact
0
Number of poles
1
Rated operating voltage
690 .. 690V
Conditioned rated short-circuit current Iq
6kA
Rated operation power at AC-3, 400 V
5.5kW
Rated permanent current Iu
20A
Number of auxiliary contacts as normally closed contact
0
Motor drive integrated
Interlockable
Number of auxiliary contacts as change-over contact
0
Number of switches
1
Degree of protection (IP), front side
IP65
Version as safety switch
Type of control element
Toggle
Version as main switch
Type of electrical connection of main circuit
Screw connection
Voltage release optional
Colour control element
Red
Rated short-time withstand current lcw
0.32kA
Suitable for distribution board installation
Version as emergency stop installation
Max. rated operation voltage Ue AC
690V
Suitable for front mounting centre
Rated permanent current at AC-21, 400 V
20A
Version as maintenance-/service switch
Suitable for floor mounting
Switching power at 400 V
5.5kW
Rated operation power at AC-23, 400 V
5.5kW
Suitable for front mounting 4-hole
Device construction
Complete device in housing
Suitable for intermediate mounting
Motor drive optional
Degree of protection (NEMA)
Other
Version as reversing switch
Rated permanent current at AC-23, 400 V
13.3A
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
