Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •EATON
Technical specifications
Height135mm
Version as emergency stop installationYes
Version as safety switchNo
Type of electrical connection of main circuitScrew connection
Rated operating voltage690 - 690V
Number of auxiliary contacts as normally closed contact0
Version as maintenance-/service switchYes
Width106mm
Rated short-time withstand current lcw0.65kA
Conditioned rated short-circuit current Iq1kA
Version as main switchYes
Number of auxiliary contacts as change-over contact0
Rated operation power at AC-3, 400 V11kW
InterlockableYes
Number of poles8
Rated operation power at AC-23, 400 V15kW
Colour control elementRed
Degree of protection (IP), front sideIP65
Number of auxiliary contacts as normally open contact0
Depth206mm
Type of control elementDoor coupling rotary drive
Rated permanent current Iu32A
Motor drive integratedNo
Number of switches1
Version as reversing switchNo
Rated permanent current at AC-23, 400 V32A
Device constructionComplete device in housing
Motor drive optionalNo
Suitable for floor mountingYes
Suitable for distribution board installationNo
Max. rated operation voltage Ue AC690V
Voltage release optionalNo
Switching power at 400 V15kW
Suitable for intermediate mountingNo
With pre-assembled cablingNo
Suitable for front mounting centreNo
Degree of protection (NEMA)12
Rated permanent current at AC-21, 400 V32A
Suitable for front mounting 4-holeNo
