Details
- •Low-voltage control systems
- •Switch disconnector (AC)
- •1 KOM
- •EATON
Technical specifications
Width200mm
Height162mm
Depth280mm
Colour housingGrey
Rated operation power at AC-3, 400 V30kW
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as normally closed contact0
Rated permanent current Iu100A
Number of poles2
Rated operating voltage690 - 690V
Conditioned rated short-circuit current Iq2kA
Material housingPlastic
Degree of protection (IP), front sideIP65
Number of auxiliary contacts as change-over contact0
Number of switches1
InterlockableYes
Motor drive integratedNo
Type of electrical connection of main circuitScrew connection
Version as emergency stop installationYes
Type of control elementDoor coupling rotary drive
Version as main switchYes
Version as safety switchNo
Version as maintenance-/service switchYes
Rated operation power at AC-23, 400 V55kW
Rated short-time withstand current lcw1.7kA
Colour control elementRed
Suitable for front mounting 4-holeNo
Suitable for front mounting centreNo
Suitable for distribution board installationNo
Suitable for intermediate mountingNo
Max. rated operation voltage Ue AC690V
Motor drive optionalNo
Voltage release optionalNo
Device constructionComplete device in housing
Rated permanent current at AC-21, 400 V100A
Switching power at 400 V55kW
Version as reversing switchNo
Rated permanent current at AC-23, 400 V100A
Degree of protection (NEMA)12
With pre-assembled cablingNo
Suitable for floor mountingNo
