Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •EATON
Technical specifications
Rated operation power at AC-3, 400 V30kW
Rated operating voltage690 - 690V
Number of auxiliary contacts as normally closed contact1
Width200mm
Motor drive integratedNo
Degree of protection (IP), front sideIP65
Number of poles6
Number of auxiliary contacts as normally open contact1
Number of switches1
Depth280mm
Type of electrical connection of main circuitScrew connection
Version as safety switchYes
Conditioned rated short-circuit current Iq2kA
Version as main switchNo
Type of control elementDoor coupling rotary drive
Number of auxiliary contacts as change-over contact0
Version as emergency stop installationNo
InterlockableYes
Rated permanent current Iu100A
Rated operation power at AC-23, 400 V55kW
Version as maintenance-/service switchNo
Height222mm
Rated short-time withstand current lcw1.7kA
Suitable for floor mountingYes
Suitable for front mounting centreNo
With pre-assembled cablingNo
Switching power at 400 V55kW
Version as reversing switchNo
Device constructionComplete device in housing
Suitable for front mounting 4-holeNo
Max. rated operation voltage Ue AC690V
Voltage release optionalNo
Suitable for intermediate mountingNo
Suitable for distribution board installationNo
Rated permanent current at AC-23, 400 V100A
Motor drive optionalNo
Rated permanent current at AC-21, 400 V100A
Degree of protection (NEMA)12
Colour control elementBlack
