Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •EATON
Technical specifications
Width160mm
Rated permanent current Iu63A
Rated operation power at AC-3, 400 V30kW
Number of auxiliary contacts as normally open contact0
Depth124mm
Rated operating voltage690 - 690V
Number of poles3
Height240mm
Number of auxiliary contacts as normally closed contact0
Conditioned rated short-circuit current Iq100kA
Number of auxiliary contacts as change-over contact0
Max. rated operation voltage Ue AC690V
Suitable for front mounting centreNo
Version as emergency stop installationNo
Version as maintenance-/service switchNo
Rated operation power at AC-23, 400 V30kW
Colour control elementBlack
Version as safety switchNo
Number of switches1
Version as main switchNo
InterlockableNo
Motor drive integratedNo
Suitable for floor mountingYes
Voltage release optionalNo
Type of electrical connection of main circuitScrew connection
Type of control elementShort thumb-grip
Suitable for front mounting 4-holeNo
Rated permanent current at AC-21, 400 V63A
Motor drive optionalNo
Suitable for intermediate mountingNo
Switching power at 400 V30kW
Rated short-time withstand current lcw1.26kA
Suitable for distribution board installationNo
Device constructionComplete device in housing
Degree of protection (IP), front sideIP65
Rated permanent current at AC-23, 400 V63A
With pre-assembled cablingNo
Version as reversing switchNo
Degree of protection (NEMA)12
Related products
