Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •EATON
Technical specifications
Number of auxiliary contacts as normally open contact1
Height280mm
Depth169mm
Width200mm
Rated operation power at AC-3, 400 V37kW
Number of poles3
Rated permanent current Iu100A
Number of auxiliary contacts as normally closed contact1
InterlockableYes
Rated operating voltage690 - 690V
Degree of protection (IP), front sideIP65
Number of switches1
Version as emergency stop installationYes
Number of auxiliary contacts as change-over contact0
Suitable for floor mountingYes
Colour control elementRed
Type of electrical connection of main circuitScrew connection
Rated operation power at AC-23, 400 V55kW
Version as main switchYes
Version as maintenance-/service switchYes
Max. rated operation voltage Ue AC690V
Motor drive optionalNo
Type of control elementDoor coupling rotary drive
Device constructionComplete device in housing
Version as safety switchYes
Rated short-time withstand current lcw2kA
Suitable for front mounting 4-holeNo
Voltage release optionalNo
Suitable for front mounting centreNo
Suitable for distribution board installationNo
Conditioned rated short-circuit current Iq80kA
Suitable for intermediate mountingNo
Motor drive integratedNo
Switching power at 400 V55kW
Version as reversing switchNo
Rated permanent current at AC-23, 400 V100A
With pre-assembled cablingNo
Rated permanent current at AC-21, 400 V100A
Degree of protection (NEMA)12
