Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •EATON
Technical specifications
Height88mm
Rated operation power at AC-3, 400 V22kW
Width88mm
Number of auxiliary contacts as normally open contact1
Rated operating voltage690 - 690V
Rated permanent current Iu63A
Number of auxiliary contacts as change-over contact0
Number of poles6
Number of auxiliary contacts as normally closed contact1
Conditioned rated short-circuit current Iq2kA
Depth182mm
Number of switches1
Degree of protection (IP), front sideIP65
Motor drive integratedNo
Version as emergency stop installationNo
InterlockableNo
Type of control elementDoor coupling rotary drive
Type of electrical connection of main circuitScrew connection
Version as main switchNo
Version as safety switchNo
Version as maintenance-/service switchNo
Colour control elementBlack
Suitable for front mounting 4-holeNo
Rated operation power at AC-23, 400 V30kW
Suitable for floor mountingYes
Rated permanent current at AC-21, 400 V63A
Suitable for distribution board installationNo
Suitable for intermediate mountingYes
Rated short-time withstand current lcw1.3kA
Max. rated operation voltage Ue AC690V
Voltage release optionalNo
Suitable for front mounting centreNo
Rated permanent current at AC-23, 400 V63A
Version as reversing switchNo
Motor drive optionalNo
Switching power at 400 V30kW
Device constructionBuilt-in device fixed built-in technique
Degree of protection (NEMA)12
With pre-assembled cablingNo
Related products
