Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •EATON
Technical specifications
Number of auxiliary contacts as normally open contact0
Rated operation power at AC-3, 400 V22kW
Version as main switchNo
Degree of protection (IP), front sideIP65
Number of poles0
Number of auxiliary contacts as change-over contact0
Type of electrical connection of main circuitScrew connection
InterlockableNo
Motor drive integratedNo
Rated permanent current Iu63A
Version as emergency stop installationNo
Version as safety switchNo
Number of auxiliary contacts as normally closed contact0
Number of switches1
Type of control elementToggle
Conditioned rated short-circuit current Iq2kA
Rated operating voltage690 - 690V
Suitable for front mounting 4-holeNo
Rated short-time withstand current lcw1.3kA
Suitable for distribution board installationNo
Suitable for front mounting centreNo
Suitable for intermediate mountingNo
Rated operation power at AC-23, 400 V30kW
Suitable for floor mountingYes
Version as maintenance-/service switchNo
Colour control elementBlack
Version as reversing switchNo
Voltage release optionalNo
Rated permanent current at AC-23, 400 V63A
Device constructionComplete device in housing
Switching power at 400 V30kW
Motor drive optionalNo
Rated permanent current at AC-21, 400 V63A
Max. rated operation voltage Ue AC690V
Degree of protection (NEMA)Other
