Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •EATON
Technical specifications
Number of auxiliary contacts as normally open contact0
Rated operation power at AC-3, 400 V5.5kW
Rated permanent current Iu20A
Rated operating voltage690 - 690V
Number of poles7
Number of auxiliary contacts as normally closed contact0
InterlockableYes
Number of switches1
Conditioned rated short-circuit current Iq6kA
Degree of protection (IP), front sideIP65
Number of auxiliary contacts as change-over contact0
Version as main switchYes
Type of electrical connection of main circuitScrew connection
Suitable for floor mountingYes
Motor drive optionalNo
Motor drive integratedNo
Version as maintenance-/service switchYes
Rated permanent current at AC-21, 400 V20A
Rated short-time withstand current lcw0.32kA
Rated operation power at AC-23, 400 V5.5kW
Max. rated operation voltage Ue AC690V
Suitable for front mounting centreNo
Suitable for intermediate mountingNo
Suitable for front mounting 4-holeNo
Version as emergency stop installationYes
Suitable for distribution board installationNo
Voltage release optionalNo
Version as safety switchNo
Colour control elementRed
Device constructionComplete device in housing
Type of control elementDoor coupling rotary drive
Degree of protection (NEMA)Other
Rated permanent current at AC-23, 400 V13.3A
Version as reversing switchNo
Switching power at 400 V5.5kW
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
T0-4-8343/I1/SVB
