Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •EATON
Technical specifications
Number of auxiliary contacts as normally closed contact0
Depth171mm
Number of auxiliary contacts as normally open contact0
Rated permanent current Iu32A
Width61mm
Height54mm
Rated operation power at AC-3, 400 V11kW
Version as maintenance-/service switchNo
InterlockableNo
Number of auxiliary contacts as change-over contact0
Degree of protection (IP), front sideIP65
Rated operating voltage690 - 690V
Number of poles0
Version as safety switchNo
Number of switches1
Type of electrical connection of main circuitScrew connection
Type of control elementShort thumb-grip
Motor drive integratedNo
Rated operation power at AC-23, 400 V15kW
Conditioned rated short-circuit current Iq1kA
Version as main switchNo
Version as emergency stop installationNo
Colour control elementBlack
Suitable for front mounting 4-holeYes
Rated short-time withstand current lcw0.65kA
Suitable for distribution board installationNo
Suitable for front mounting centreNo
Voltage release optionalNo
Max. rated operation voltage Ue AC690V
Suitable for intermediate mountingNo
Motor drive optionalNo
Suitable for floor mountingNo
Rated permanent current at AC-23, 400 V32A
Version as reversing switchNo
Rated permanent current at AC-21, 400 V32A
Device constructionBuilt-in device fixed built-in technique
Switching power at 400 V15kW
With pre-assembled cablingNo
Degree of protection (NEMA)12
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
T3-9-SOND*/E
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Switch disconnector (low voltage)
- 1 KOM
- EATON
DetailsTechnical specificationsRelated products
Technical specifications
Number of auxiliary contacts as normally closed contact
0
Depth
171mm
Number of auxiliary contacts as normally open contact
0
Rated permanent current Iu
32A
Width
61mm
Height
54mm
Rated operation power at AC-3, 400 V
11kW
Version as maintenance-/service switch
Interlockable
Number of auxiliary contacts as change-over contact
0
Degree of protection (IP), front side
IP65
Rated operating voltage
690 .. 690V
Number of poles
0
Version as safety switch
Number of switches
1
Type of electrical connection of main circuit
Screw connection
Type of control element
Short thumb-grip
Motor drive integrated
Rated operation power at AC-23, 400 V
15kW
Conditioned rated short-circuit current Iq
1kA
Version as main switch
Version as emergency stop installation
Colour control element
Black
Suitable for front mounting 4-hole
Rated short-time withstand current lcw
0.65kA
Suitable for distribution board installation
Suitable for front mounting centre
Voltage release optional
Max. rated operation voltage Ue AC
690V
Suitable for intermediate mounting
Motor drive optional
Suitable for floor mounting
Rated permanent current at AC-23, 400 V
32A
Version as reversing switch
Rated permanent current at AC-21, 400 V
32A
Device construction
Built-in device fixed built-in technique
Switching power at 400 V
15kW
With pre-assembled cabling
Degree of protection (NEMA)
12
Related products
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
