Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •EATON
Technical specifications
Number of auxiliary contacts as normally closed contact0
InterlockableYes
Number of auxiliary contacts as normally open contact0
Type of control elementDoor coupling rotary drive
Degree of protection (IP), front sideIP65
Version as emergency stop installationNo
Number of switches1
Rated operating voltage690 - 690V
Version as main switchYes
Number of auxiliary contacts as change-over contact0
Type of electrical connection of main circuitScrew connection
Motor drive integratedNo
Conditioned rated short-circuit current Iq1kA
Rated operation power at AC-3, 400 V11kW
Rated short-time withstand current lcw0.65kA
Version as safety switchNo
Version as maintenance-/service switchYes
Rated operation power at AC-23, 400 V15kW
Degree of protection (NEMA)Other
Colour control elementRed
Rated permanent current at AC-23, 400 V32A
Motor drive optionalNo
Voltage release optionalNo
Suitable for intermediate mountingNo
Rated permanent current at AC-21, 400 V32A
Switching power at 400 V15kW
Device constructionBuilt-in device fixed built-in technique
Suitable for front mounting centreNo
Suitable for front mounting 4-holeYes
Suitable for floor mountingNo
Suitable for distribution board installationNo
Version as reversing switchNo
Rated permanent current Iu32A
Number of poles0
Max. rated operation voltage Ue AC690V
