Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •EATON
Technical specifications
Conditioned rated short-circuit current Iq1kA
Rated permanent current Iu32A
Number of poles0
Number of auxiliary contacts as normally open contact0
Rated operating voltage690 - 690V
Rated operation power at AC-3, 400 V11kW
Number of auxiliary contacts as normally closed contact0
Number of switches1
Rated permanent current at AC-21, 400 V32A
Suitable for intermediate mountingYes
Motor drive integratedNo
Type of control elementToggle
Colour control elementBlack
Suitable for front mounting centreNo
Suitable for distribution board installationNo
Suitable for floor mountingYes
Motor drive optionalNo
Device constructionBuilt-in device fixed built-in technique
Number of auxiliary contacts as change-over contact0
Max. rated operation voltage Ue AC690V
InterlockableNo
Version as maintenance-/service switchNo
Voltage release optionalNo
Type of electrical connection of main circuitScrew connection
Degree of protection (IP), front sideIP00
Version as emergency stop installationNo
Version as main switchNo
Switching power at 400 V15kW
Suitable for front mounting 4-holeNo
Rated operation power at AC-23, 400 V15kW
Version as safety switchNo
Rated short-time withstand current lcw0.65kA
Version as reversing switchNo
Rated permanent current at AC-23, 400 V32A
Degree of protection (NEMA)Other
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
T3-5-SOND*/XZ
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Switch disconnector
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Conditioned rated short-circuit current Iq
1kA
Rated permanent current Iu
32A
Number of poles
0
Number of auxiliary contacts as normally open contact
0
Rated operating voltage
690 .. 690V
Rated operation power at AC-3, 400 V
11kW
Number of auxiliary contacts as normally closed contact
0
Number of switches
1
Rated permanent current at AC-21, 400 V
32A
Suitable for intermediate mounting
Motor drive integrated
Type of control element
Toggle
Colour control element
Black
Suitable for front mounting centre
Suitable for distribution board installation
Suitable for floor mounting
Motor drive optional
Device construction
Built-in device fixed built-in technique
Number of auxiliary contacts as change-over contact
0
Max. rated operation voltage Ue AC
690V
Interlockable
Version as maintenance-/service switch
Voltage release optional
Type of electrical connection of main circuit
Screw connection
Degree of protection (IP), front side
IP00
Version as emergency stop installation
Version as main switch
Switching power at 400 V
15kW
Suitable for front mounting 4-hole
Rated operation power at AC-23, 400 V
15kW
Version as safety switch
Rated short-time withstand current lcw
0.65kA
Version as reversing switch
Rated permanent current at AC-23, 400 V
32A
Degree of protection (NEMA)
Other
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
