Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •EATON
Technical specifications
Number of auxiliary contacts as normally closed contact0
Rated permanent current Iu63A
Number of auxiliary contacts as normally open contact0
Suitable for front mounting centreNo
Rated operation power at AC-3, 400 V22kW
Rated short-time withstand current lcw1.3kA
Degree of protection (IP), front sideIP65
Rated operating voltage690 - 690V
InterlockableYes
Suitable for front mounting 4-holeNo
Motor drive integratedNo
Version as main switchYes
Version as safety switchNo
Type of control elementDoor coupling rotary drive
Number of auxiliary contacts as change-over contact0
Rated operation power at AC-23, 400 V30kW
Type of electrical connection of main circuitScrew connection
Number of switches1
Version as maintenance-/service switchYes
Version as emergency stop installationNo
Conditioned rated short-circuit current Iq2kA
Number of poles0
Suitable for floor mountingYes
Colour control elementRed
Suitable for distribution board installationNo
Rated permanent current at AC-23, 400 V63A
Suitable for intermediate mountingYes
Max. rated operation voltage Ue AC690V
Motor drive optionalNo
Degree of protection (NEMA)Other
Rated permanent current at AC-21, 400 V63A
Version as reversing switchNo
Switching power at 400 V30kW
Device constructionBuilt-in device fixed built-in technique
Voltage release optionalNo
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
T5B-8-SOND*/V/SVB
