Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •EATON
Technical specifications
Rated operation power at AC-3, 400 V30kW
Rated operating voltage690 - 690V
Number of auxiliary contacts as normally closed contact0
Rated permanent current Iu100A
Number of poles0
Degree of protection (IP), front sideIP65
Number of switches1
Conditioned rated short-circuit current Iq2kA
Number of auxiliary contacts as change-over contact0
Number of auxiliary contacts as normally open contact0
Version as main switchYes
Version as emergency stop installationNo
InterlockableYes
Type of electrical connection of main circuitScrew connection
Motor drive integratedNo
Type of control elementDoor coupling rotary drive
Version as safety switchNo
Rated short-time withstand current lcw1.7kA
Suitable for floor mountingNo
Colour control elementRed
Version as maintenance-/service switchYes
Suitable for front mounting centreNo
Max. rated operation voltage Ue AC690V
Rated operation power at AC-23, 400 V55kW
Suitable for distribution board installationNo
Suitable for intermediate mountingNo
Suitable for front mounting 4-holeYes
Switching power at 400 V55kW
Motor drive optionalNo
Rated permanent current at AC-23, 400 V100A
Version as reversing switchNo
Degree of protection (NEMA)Other
Device constructionBuilt-in device fixed built-in technique
Rated permanent current at AC-21, 400 V100A
Voltage release optionalNo
