Details
- •Non standart switch, 100A
- •Low-voltage industrial components
- •Switch disconnector
- •Minimum order quantity: 1 pcs
- •EATON
Technical specifications
Rated operation power at AC-3, 400 V30kW
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Rated operating voltage690 - 690V
Conditioned rated short-circuit current Iq2kA
InterlockableYes
Degree of protection (IP), front sideIP65
Version as safety switchNo
Number of auxiliary contacts as change-over contact0
Motor drive integratedNo
Version as emergency stop installationNo
Suitable for floor mountingYes
Suitable for front mounting centreNo
Suitable for front mounting 4-holeNo
Version as maintenance-/service switchYes
Number of switches1
Rated short-time withstand current lcw1.7kA
Type of control elementDoor coupling rotary drive
Rated operation power at AC-23, 400 V55kW
Version as main switchYes
Suitable for distribution board installationNo
Type of electrical connection of main circuitScrew connection
Device constructionBuilt-in device fixed built-in technique
Suitable for intermediate mountingYes
Motor drive optionalNo
Voltage release optionalNo
Rated permanent current at AC-21, 400 V100A
Colour control elementRed
Switching power at 400 V55kW
Degree of protection (NEMA)Other
Rated permanent current at AC-23, 400 V100A
Version as reversing switchNo
Rated permanent current Iu100A
Number of poles0
Max. rated operation voltage Ue AC690V
