Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •EATON
Technical specifications
Degree of protection (IP), front sideIP00
Number of auxiliary contacts as normally open contact0
Rated operation power at AC-3, 400 V30kW
Conditioned rated short-circuit current Iq2kA
Motor drive integratedNo
Number of poles0
InterlockableNo
Rated operating voltage690 - 690V
Number of auxiliary contacts as change-over contact0
Rated permanent current Iu100A
Number of auxiliary contacts as normally closed contact0
Number of switches1
Version as main switchNo
Type of control elementToggle
Type of electrical connection of main circuitScrew connection
Version as emergency stop installationNo
Rated short-time withstand current lcw1.7kA
Rated operation power at AC-23, 400 V55kW
Version as maintenance-/service switchNo
Colour control elementBlack
Motor drive optionalNo
Suitable for front mounting 4-holeNo
Version as safety switchNo
Max. rated operation voltage Ue AC690V
Suitable for distribution board installationNo
Suitable for intermediate mountingNo
Suitable for floor mountingNo
Voltage release optionalNo
Suitable for front mounting centreNo
Rated permanent current at AC-23, 400 V100A
Switching power at 400 V55kW
Device constructionBuilt-in device fixed built-in technique
Degree of protection (NEMA)Other
Version as reversing switchNo
Rated permanent current at AC-21, 400 V100A
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
T5-5-SOND*/X
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Switch disconnector
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Degree of protection (IP), front side
IP00
Number of auxiliary contacts as normally open contact
0
Rated operation power at AC-3, 400 V
30kW
Conditioned rated short-circuit current Iq
2kA
Motor drive integrated
Number of poles
0
Interlockable
Rated operating voltage
690 .. 690V
Number of auxiliary contacts as change-over contact
0
Rated permanent current Iu
100A
Number of auxiliary contacts as normally closed contact
0
Number of switches
1
Version as main switch
Type of control element
Toggle
Type of electrical connection of main circuit
Screw connection
Version as emergency stop installation
Rated short-time withstand current lcw
1.7kA
Rated operation power at AC-23, 400 V
55kW
Version as maintenance-/service switch
Colour control element
Black
Motor drive optional
Suitable for front mounting 4-hole
Version as safety switch
Max. rated operation voltage Ue AC
690V
Suitable for distribution board installation
Suitable for intermediate mounting
Suitable for floor mounting
Voltage release optional
Suitable for front mounting centre
Rated permanent current at AC-23, 400 V
100A
Switching power at 400 V
55kW
Device construction
Built-in device fixed built-in technique
Degree of protection (NEMA)
Other
Version as reversing switch
Rated permanent current at AC-21, 400 V
100A
