Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •EATON
Technical specifications
Height88mm
Rated operation power at AC-3, 400 V30kW
Conditioned rated short-circuit current Iq2kA
Rated operation power at AC-23, 400 V55kW
Version as maintenance-/service switchNo
Version as safety switchNo
Depth264mm
Rated permanent current Iu100A
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as change-over contact0
Degree of protection (IP), front sideIP65
Version as main switchNo
Number of switches1
Type of control elementShort thumb-grip
InterlockableNo
Motor drive integratedNo
Version as emergency stop installationNo
Number of poles0
Type of electrical connection of main circuitScrew connection
Rated operating voltage690 - 690V
Width88mm
Number of auxiliary contacts as normally open contact0
Rated short-time withstand current lcw1.7kA
Switching power at 400 V55kW
Suitable for intermediate mountingYes
Suitable for floor mountingYes
Device constructionBuilt-in device fixed built-in technique
Degree of protection (NEMA)12
Suitable for front mounting centreNo
Suitable for distribution board installationNo
With pre-assembled cablingNo
Colour control elementBlack
Suitable for front mounting 4-holeNo
Rated permanent current at AC-23, 400 V100A
Motor drive optionalNo
Max. rated operation voltage Ue AC690V
Version as reversing switchNo
Rated permanent current at AC-21, 400 V100A
Voltage release optionalNo
