Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •EATON
Technical specifications
Rated operation power at AC-3, 400 V11kW
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as change-over contact0
Degree of protection (IP), front sideIP65
Number of poles0
Rated operating voltage690 - 690V
Number of auxiliary contacts as normally closed contact0
Conditioned rated short-circuit current Iq1kA
Rated permanent current Iu32A
Number of switches1
InterlockableYes
Type of electrical connection of main circuitScrew connection
Version as main switchYes
Suitable for front mounting 4-holeYes
Version as emergency stop installationNo
Rated short-time withstand current lcw0.65kA
Version as safety switchNo
Motor drive integratedNo
Suitable for floor mountingNo
Type of control elementDoor coupling rotary drive
Suitable for front mounting centreNo
Version as maintenance-/service switchYes
Rated operation power at AC-23, 400 V15kW
Colour control elementRed
Rated permanent current at AC-23, 400 V32A
Suitable for distribution board installationNo
Voltage release optionalNo
Device constructionBuilt-in device fixed built-in technique
Motor drive optionalNo
Rated permanent current at AC-21, 400 V32A
Max. rated operation voltage Ue AC690V
Suitable for intermediate mountingNo
Version as reversing switchNo
Switching power at 400 V15kW
Degree of protection (NEMA)Other
