Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •EATON
Technical specifications
Rated short-time withstand current lcw1.7kA
Degree of protection (IP), front sideIP65
Type of control elementDoor coupling rotary drive
Number of auxiliary contacts as change-over contact0
Rated permanent current Iu100A
Version as safety switchNo
Number of switches1
Rated operating voltage690 - 690V
Number of auxiliary contacts as normally open contact0
Rated operation power at AC-3, 400 V30kW
Number of auxiliary contacts as normally closed contact0
Version as main switchYes
Type of electrical connection of main circuitScrew connection
Version as maintenance-/service switchYes
InterlockableYes
Rated operation power at AC-23, 400 V55kW
Colour control elementBlack
Motor drive integratedNo
Version as emergency stop installationNo
Number of poles0
Conditioned rated short-circuit current Iq2kA
Suitable for intermediate mountingNo
Suitable for front mounting 4-holeYes
Suitable for front mounting centreNo
Motor drive optionalNo
Device constructionBuilt-in device fixed built-in technique
Suitable for distribution board installationNo
Suitable for floor mountingNo
Max. rated operation voltage Ue AC690V
Voltage release optionalNo
Rated permanent current at AC-23, 400 V100A
Degree of protection (NEMA)Other
Rated permanent current at AC-21, 400 V100A
Switching power at 400 V55kW
Version as reversing switchNo
