Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •EATON
Technical specifications
Number of auxiliary contacts as normally open contact0
Degree of protection (IP), front sideIP65
Conditioned rated short-circuit current Iq2kA
Rated operating voltage690 - 690V
Number of poles0
Number of auxiliary contacts as normally closed contact0
Number of switches1
Rated permanent current Iu100A
InterlockableYes
Rated operation power at AC-3, 400 V30kW
Type of electrical connection of main circuitScrew connection
Motor drive integratedNo
Version as main switchYes
Version as safety switchNo
Version as emergency stop installationNo
Version as maintenance-/service switchYes
Type of control elementDoor coupling rotary drive
Number of auxiliary contacts as change-over contact0
Suitable for front mounting 4-holeNo
Rated short-time withstand current lcw1.7kA
Colour control elementBlack
Suitable for front mounting centreNo
Suitable for floor mountingYes
Voltage release optionalNo
Max. rated operation voltage Ue AC690V
Rated permanent current at AC-23, 400 V100A
Rated permanent current at AC-21, 400 V100A
Motor drive optionalNo
Switching power at 400 V55kW
Suitable for intermediate mountingYes
Rated operation power at AC-23, 400 V55kW
Device constructionBuilt-in device fixed built-in technique
Version as reversing switchNo
Degree of protection (NEMA)Other
Suitable for distribution board installationNo
